WEG Electric Corporation Electric Motors Model 00218ET3W100L-W22 Service, Sales, Replacement Parts
WEG Electric Corporation 00218ET3W100L-W22 WEG Electric Corporation Electric Motors Model 00218ET3W100L-W22 Service, Sales, Replacement Parts
Product information
Key Features
- Motor Category General Purpose Motor
- Motor Phase 3 ph
- Motor Horsepower 3 hp
- kW 2.20 kW
- Synchronous Rpm 1800 rpm
- Motor Supply Voltage 220/240/380/415//460 V
- Frame Size 100L
- Enclosure Type TEFC (Totally Enclosed Fan Cooled)
- Frequency Rating 50/60 Hz
- Duty Condition Type Continuous Duty
WEG Electric Corporation
- Model #:
- 00218ET3W100L-W22
- Part #:
- 00218ET3W100L-W22
- New/Surplus $ 1022
- Refurb. Price $715 Save up to $ 307
- Repair Price $511 Save up to $ 511
00218ET3W100L-W22 WEG Electric Corporation | BUY OR REPAIR
Overview
IEC Frame AC Motor – 2.20 kW, 1800 rpm, 3 ph, 220/240/380/415//460 V, 100L Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 50/60 Hz, Foot Mount, Continuous Duty
Features
- Motor Category General Purpose Motor
- Motor Phase 3 ph
- Motor Horsepower 3 hp
- kW 2.20 kW
- Synchronous Rpm 1800 rpm
- Motor Supply Voltage 220/240/380/415//460 V
- Frame Size 100L
- Enclosure Type TEFC (Totally Enclosed Fan Cooled)
- Frequency Rating 50/60 Hz
- Duty Condition Type Continuous Duty
- Volts @ Frequency Contact Global Electronic Services
- Shaft Diameter 28 mm
- Overall Length C Dimension 14.80 in
- Service Factor 1.25
- Frame Material Cast Iron
- Insulation Class F
- IP Rating 55
- Standards Met UL CSA CE
- Harmonization Code 8501.52.4000
- Weight 76.33 lbs
- Manufacturer Catalog Contact Global Electronic Services
- UPC_NO 7891327440630
- Mounting Type Foot
- Product Type IEC Frame Motors
