US Motors (Nidec) Electric Motors Model 1933 Service, Sales, Replacement Parts
US Motors (Nidec) 1933 US Motors (Nidec) Electric Motors Model 1933 Service, Sales, Replacement Parts
Product information
Key Features
- Motor Phase 1 ph
- Motor Horsepower 1/4 hp
- Synchronous Rpm 1200 rpm
- Country of Origin MEX
- Motor Supply Voltage 115 V
- Frame Size 48Y
- Enclosure Type OAO (Open Air-Over)
- Frequency Rating 60 Hz
- Base RPM 1075 rpm
- Duty Condition Type Continuous Duty
US Motors (Nidec)
- Model #:
- 1933
- Part #:
- 1933
- New/Surplus $ 709
- Refurb. Price $496 Save up to $ 213
- Repair Price $355 Save up to $ 354
1933 US Motors (Nidec) | BUY OR REPAIR
Overview
Yoke Pedestal Fan Motor – 1/4 hp, 1200 rpm, 1 ph, 115 V, 48Y Frame, OAO (Open Air-Over) Enclosure, 60 Hz, 1075 rpm Base, Yoke Mount, Continuous Duty
Features
- Motor Phase 1 ph
- Motor Horsepower 1/4 hp
- Synchronous Rpm 1200 rpm
- Country of Origin MEX
- Motor Supply Voltage 115 V
- Frame Size 48Y
- Enclosure Type OAO (Open Air-Over)
- Frequency Rating 60 Hz
- Base RPM 1075 rpm
- Duty Condition Type Continuous Duty
- Mounting Type Yoke
- Thermal Protection Automatic Reset
- Full Load Current 5.70 A
- Motor Poles 6
- Number Of Speeds 2
- Description US Motors (Nidec) Electric Motors 1933
- Description Keyword 1/4 hp
- Shaft Diameter 0.5000 in
- Overall Length C Dimension 10.1 in
- Service Factor 1.00
- Frame Material Steel
- Insulation Class B
- Standards Met NEMA
- Weight 19 lbs
- Applications Direct Drive Exhaust Livestock Houses Vent Fans In Poultry
- Harmonization Code 8501.40.3040
- Manufacturer Upc Number 786382075309
- UPC_NO 786382075309
- Manufacturer Product Page Contact Global Electronic Services
- Model K055DAC8802021B
- Motor Category Yoke Pedestal Fan Motor
- Max Allowable Current 5.7 A
- Product Types AC Motors
- Torque 27.98 ft-lbs
- Opposite Drive End Bearing Ball
- Product Type General Purpose Motors
