Thermal overload relay, TeSys LRD, 5.5…8 A, class 10A
Schneider Electric LRD12 Thermal overload relay, TeSys LRD, 5.5…8 A, class 10A
Product information
Key Features
- range TeSys
- product name TeSys LRD
- product or component type Differential thermal overload relay
- device short name LRD
- relay application Motor protection
Schneider Electric
- Model #:
- LRD12
- Part #:
- LRD12
LRD12 Schneider Electric | BUY OR REPAIR
Overview
Low Voltage Products and Systems > Motor Starters and Protection Components > Thermal Overload Relay > TeSys LRD > LRD12
Features
- range TeSys
- product name TeSys LRD
- product or component type Differential thermal overload relay
- device short name LRD
- relay application Motor protection
- product compatibility LC1D18 LC1D25 LC1D32 LC1D12 LC1D09 LC1D38
- network type DC AC
- thermal overload class Class 10A
- thermal protection adjustment range 5.5…8 A
- [Ui] rated insulation voltage Power circuit: 600 V conforming to CSA Power circuit: 600 V conforming to UL Power circuit: 690 V conforming to IEC 60947-4-1
- network frequency 0...400 Hz
- mounting support Plate
- tripping threshold with specific accessories Rail
- [Ith] conventional free air thermal current with specific accessories Under contactor
- permissible current 1.14 +/- 0.06 Ir conforming to IEC 60947-4-1
- 5 A for signalling circuit
- 1.5 A at 240 V AC-15 for signalling circuit 0.1 A at 250 V DC-13 for signalling circuit
