Intermatic ET2705CP Automation Switches
Intermatic ET2705CP Intermatic ET2705CP Automation Switches
Product information
Key Features
- Catalog Number ET2705CP
- Manufacturer Intermatic
- Brand Intermatic
- Country of Origin Mexico
- Made in USA No
- Action 1 x SPST
- Amperage Rating 30
- Application Exterior Lighting Interior Lighting Security Lighting Parking Lot Lighting Bell Ringing Electric Motors Electric Pump Indoor/Outdoor
- Connection Wire Lead
- Contact Configuration 1 NO
- Contact Rating 30 AMP @ 120/240 VAC 20 AMP @ 28 VDC (Resistive) 30 AMP @ 120/240 VAC (Inductive) 5 AMP @ 120/240 VAC (Tungsten) 20 AMP @ 120 - 277 VAC 10 AMP @ 120/277 VAC (Ballast)
- Enclosure Type 3R Plastic
- Mounting Wall
- Number of Poles 1
- Special Features Features: Automatic Voltage Detection for Fast Easy Out-of-the-Box Installations Control Different Load Types and Voltages from a Single Control Adjust Daylight Savings Time Through Software Rather than DIP Switches Configurable Outputs Allow These Models to Cover Various Types of Applications with a Single Clock New Mode of Operation Allows For Manual On/Off Buttons to Operate as a 2-Hour Override Non-Volatile Eeprom Memory Protects Programming Indefinitely 2 Year Warranty
- Standard UL Rating Meet Title 20/24 Compliance
- UPC 078275148109
- GTIN 00078275148109
- Item Type Electronic
- Operating Temperature -40 to +155 DEG F -40 to +68 DEG C
- Timing Range 1 MIN - 6 DAYS 23 HR 59 MIN
- Voltage Rating 120 - 277
Intermatic
- Model #:
- ET2705CP
- Part #:
- ET2705CP
- New/Surplus $ 545
- Refurb. Price $382 Save up to $ 163
- Repair Price $273 Save up to $ 272
ET2705CP Intermatic | BUY OR REPAIR
Overview
Industrial Automation and Control, Automation Switches, Time Switch, 7-Day/365 Day 1-Circuit Electronic Control, 120-277 VAC, SPST, Indoor/Outdoor Plastic Enclosure
Features
- Catalog Number ET2705CP
- Manufacturer Intermatic
- Brand Intermatic
- Country of Origin Mexico
- Made in USA No
- Action 1 x SPST
- Amperage Rating 30
- Application Exterior Lighting Interior Lighting Security Lighting Parking Lot Lighting Bell Ringing Electric Motors Electric Pump Indoor/Outdoor
- Connection Wire Lead
- Contact Configuration 1 NO
- Contact Rating 30 AMP @ 120/240 VAC 20 AMP @ 28 VDC (Resistive) 30 AMP @ 120/240 VAC (Inductive) 5 AMP @ 120/240 VAC (Tungsten) 20 AMP @ 120 - 277 VAC 10 AMP @ 120/277 VAC (Ballast)
- Enclosure Type 3R Plastic
- Mounting Wall
- Number of Poles 1
- Special Features Features: Automatic Voltage Detection for Fast Easy Out-of-the-Box Installations Control Different Load Types and Voltages from a Single Control Adjust Daylight Savings Time Through Software Rather than DIP Switches Configurable Outputs Allow These Models to Cover Various Types of Applications with a Single Clock New Mode of Operation Allows For Manual On/Off Buttons to Operate as a 2-Hour Override Non-Volatile Eeprom Memory Protects Programming Indefinitely 2 Year Warranty
- Standard UL Rating Meet Title 20/24 Compliance
- UPC 078275148109
- GTIN 00078275148109
- Item Type Electronic
- Operating Temperature -40 to +155 DEG F -40 to +68 DEG C
- Timing Range 1 MIN - 6 DAYS 23 HR 59 MIN
- Voltage Rating 120 - 277
