circuit breaker EasyPact Vigi CVS160B, 25 kA at 415 VAC, 160 A rating TM-D trip unit, MH Vigi module, 4P 4d
Schneider Electric LV516383 circuit breaker EasyPact Vigi CVS160B, 25 kA at 415 VAC, 160 A rating TM-D trip unit, MH Vigi module, 4P 4d
Product information
Key Features
- range of product Easypact CVS100...250
- product or component type Earth leakage circuit breaker
- device short name Vigi CVS160B
- device application Distribution
- poles description 4P
Schneider Electric
- Model #:
- LV516383
- Part #:
- LV516383
LV516383 Schneider Electric | BUY OR REPAIR
Overview
Low Voltage Products and Systems > Circuit Breakers and Switches > EasyPact circuit breakers and switches > EasyPact CVS > LV516383
Features
- range of product Easypact CVS100...250
- product or component type Earth leakage circuit breaker
- device short name Vigi CVS160B
- device application Distribution
- poles description 4P
- protected poles description 4d
- neutral position Left
- Earth leakage protection (Vigi add on) With
- [In] rated current 160 A at 40 °C
- breaking capacity code B
- network type AC
- [Icu] Breaking capacity 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
- utilisation category Category A
- trip unit name TM-D
- trip unit technology Thermal-magnetic
- trip unit rating 160 A at 40 °C
- protection type Overload protection (thermal) Short-circuit protection (magnetic) Earth-leakage protection
- earth-leakage add-on module name MH
- network frequency 50/60 Hz
- control type Toggle
- mounting mode Fixed
- mounting support Backplate
- upside connection Front
