CIRCUIT BREAKER EASYPACT EZC630H – TMD – 600 A – 3 POLES 3D

Features

• range of product EasyPact
• product or component type Circuit breaker
• device short name Easypact EZC630H
• circuit breaker name Easypact EZC630H
• device application Distribution
• poles description 3P
• protected poles description 3t
• network type DC AC
• network frequency 50/60 Hz
• [In] rated current 600 A at 40 °C
• [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2
• [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2
• [Ue] rated operational voltage 250 V DC conforming to IEC 60947-2 440 V AC 50/60 Hz conforming to IEC 60947-2
• breaking capacity code H
• breaking capacity 50 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 70 kA Icu at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 50 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
• [Ics] rated service breaking capacity 25 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 70 kA at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 50 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2 50 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
• suitability for isolation Yes conforming to IEC 60947-2
• utilisation category Category A
• trip unit name TM-D
• trip unit technology Thermal-magnetic
• trip unit rating 600 A at 50 °C
• protection type Short-circuit protection Overload protection
• pollution degree 3 conforming to IEC 60947
• control type Toggle
• mounting mode Fixed
• mounting support Backplate
• upside connection Front
• downside connection Front
