circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d
Schneider Electric LV540506 circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 400 A rating ETS 2.3 electronic trip unit, 4P 4d
Product information
Key Features
- range of product Easypact CVS400...630
- product or component type Circuit breaker
- device short name CVS400F
- device application Distribution
- poles description 4P
Schneider Electric
- Model #:
- LV540506
- Part #:
- LV540506
LV540506 Schneider Electric | BUY OR REPAIR
Overview
Low Voltage Products and Systems > Circuit Breakers and Switches > EasyPact circuit breakers and switches > EasyPact CVS > LV540506
Features
- range of product Easypact CVS400...630
- product or component type Circuit breaker
- device short name CVS400F
- device application Distribution
- poles description 4P
- protected poles description 4d 3d + N/2 3d
- neutral position Left
- Earth leakage protection (Vigi add on) Without
- [In] rated current 400 A at 40 °C
- breaking capacity code F
- network type AC
- [Icu] Breaking capacity 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 30 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
- utilisation category Category A
- trip unit name ETS 2.3
- trip unit technology Electronic
- trip unit rating 400 A at 40 °C
- protection type Short time short-circuit protection Instantaneous short-circuit protection Overload protection (long time)
- network frequency 50/60 Hz
- control type Toggle
- mounting mode Fixed
- mounting support Backplate
- upside connection Front
