circuit breaker EasyPact CVS250F, 36 kA at 415 VAC, 200 A rating thermal magnetic TM-D trip unit, 4P 3d
Schneider Electric LV525342 circuit breaker EasyPact CVS250F, 36 kA at 415 VAC, 200 A rating thermal magnetic TM-D trip unit, 4P 3d
Product information
Key Features
- range of product Easypact CVS100...250
- product or component type Circuit breaker
- device short name CVS250F
- device application Distribution
- poles description 4P
Schneider Electric
- Model #:
- LV525342
- Part #:
- LV525342
LV525342 Schneider Electric | BUY OR REPAIR
Overview
Low Voltage Products and Systems > Circuit Breakers and Switches > EasyPact circuit breakers and switches > EasyPact CVS > LV525342
Features
- range of product Easypact CVS100...250
- product or component type Circuit breaker
- device short name CVS250F
- device application Distribution
- poles description 4P
- protected poles description 3d
- neutral position Left
- Earth leakage protection (Vigi add on) Without
- [In] rated current 250 A at 40 °C
- breaking capacity code F
- network type AC
- [Icu] Breaking capacity 36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 70 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
- utilisation category Category A
- trip unit name TM-D
- trip unit technology Thermal-magnetic
- trip unit rating 200 A at 40 °C
- protection type Short-circuit protection (magnetic) Overload protection (thermal)
- network frequency 50/60 Hz
- control type Toggle
- mounting mode Fixed
- mounting support Backplate
- upside connection Front
