circuit breaker EasyPact CVS100B, 25 kA at 415 VAC, 12.5 A rating magnetic MA trip unit, 3P 3d
Schneider Electric LV510432 circuit breaker EasyPact CVS100B, 25 kA at 415 VAC, 12.5 A rating magnetic MA trip unit, 3P 3d
Product information
Key Features
- range of product Easypact CVS100...250
- product or component type Circuit breaker
- device short name CVS100B
- device application Motor
- poles description 3P
Schneider Electric
- Model #:
- LV510432
- Part #:
- LV510432
LV510432 Schneider Electric | BUY OR REPAIR
Overview
Low Voltage Products and Systems > Circuit Breakers and Switches > EasyPact circuit breakers and switches > EasyPact CVS > LV510432
Features
- range of product Easypact CVS100...250
- product or component type Circuit breaker
- device short name CVS100B
- device application Motor
- poles description 3P
- protected poles description 3d
- Earth leakage protection (Vigi add on) Without
- [In] rated current 100 A at 40 °C
- breaking capacity code B
- network type AC
- [Icu] Breaking capacity 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
- utilisation category Category A
- trip unit name MA
- trip unit technology Magnetic
- trip unit rating 12.5 A at 40 °C
- protection type Short-circuit protection (magnetic)
- network frequency 50/60 Hz
- control type Toggle
- mounting mode Fixed
- mounting support Backplate
- upside connection Front
