CIRCUIT BREAKER COMPACT NSX800 DC – TM-DC – 800 A – 2P
Schneider Electric LV438362 CIRCUIT BREAKER COMPACT NSX800 DC – TM-DC – 800 A – 2P
Product information
Key Features
- range Compact
- product name Compact NSX DC
- range of product NSX400...630 DC
- device short name Compact NSX800 DC
- product or component type Circuit breaker
Schneider Electric
- Model #:
- LV438362
- Part #:
- LV438362
LV438362 Schneider Electric | BUY OR REPAIR
Overview
Low Voltage Products and Systems > Circuit Breakers and Switches > Molded Case Circuit Breakers – MCCBs > Compact NSX for Direct Current > LV438362
Features
- range Compact
- product name Compact NSX DC
- range of product NSX400...630 DC
- device short name Compact NSX800 DC
- product or component type Circuit breaker
- device application Distribution
- poles description 2P
- protected poles description 2t
- [In] rated current 800 A at 40 °C
- [Ue] rated operational voltage 600 V DC conforming to IEC 60947-2
- network type DC
- suitability for isolation Yes conforming to IEC 60947-2
- utilisation category Category A
- [Icu] rated ultimate short-circuit breaking capacity 50 kA Icu at 250 V DC 1P conforming to IEC 60947-2 50 kA Icu at 600 V DC 2P conforming to IEC 60947-2
- Performance level N 50 kA 250 V DC
- trip unit name TM-DC
- trip unit technology Thermal-magnetic
- control type Toggle
- Circuit breaker mounting mode Fixed
- [Ui] rated insulation voltage 750 V DC conforming to IEC 60947-2
- [Uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947-2
- [Ics] rated service short-circuit breaking capacity 4.5 kA at 600 V DC conforming to IEC 60947-2
- mechanical durability 5000 cycles
- mounting support Backplate
