US Motors (Nidec) Electric Motors Model 1917 Service, Sales, Replacement Parts
US Motors (Nidec) 1917 US Motors (Nidec) Electric Motors Model 1917 Service, Sales, Replacement Parts
Product information
Key Features
- Motor Phase 1 ph
- Motor Horsepower 1/4 hp
- Synchronous Rpm 1200 rpm
- Country of Origin MEX
- Motor Supply Voltage 115 V
- Frame Size 48YZ
- Enclosure Type TEAO (Totally Enclosed Air Over)
- Frequency Rating 60 Hz
- Base RPM 1075 rpm
- Duty Condition Type Continuous Duty
US Motors (Nidec)
- Model #:
- 1917
- Part #:
- 1917
- New/Surplus $ 522
- Refurb. Price $365 Save up to $ 157
- Repair Price $261 Save up to $ 261
1917 US Motors (Nidec) | BUY OR REPAIR
Overview
Yoke Pedestal Fan Motor – 1/4 hp, 1200 rpm, 1 ph, 115 V, 48YZ Frame, TEAO (Totally Enclosed Air Over) Enclosure, 60 Hz, 1075 rpm Base, Yoke Mount, Continuous Duty
Features
- Motor Phase 1 ph
- Motor Horsepower 1/4 hp
- Synchronous Rpm 1200 rpm
- Country of Origin MEX
- Motor Supply Voltage 115 V
- Frame Size 48YZ
- Enclosure Type TEAO (Totally Enclosed Air Over)
- Frequency Rating 60 Hz
- Base RPM 1075 rpm
- Duty Condition Type Continuous Duty
- Mounting Type Yoke
- Thermal Protection Automatic Reset
- Full Load Current 4.20 A
- Full Load Efficiency 56.0 %
- Motor Poles 6
- Number Of Speeds 2
- Description US Motors (Nidec) Electric Motors 1917
- Description Keyword 1/4 hp
- Shaft Diameter 0.5000 in
- Overall Length C Dimension 10.5 in
- NEMA Design Class N
- Service Factor 1.00
- Frame Material Steel
- Insulation Class A
- Standards Met NEMA
- Weight 17 lbs
- Applications Air Circulators Where Motor Is Mounted Directly to Fan Column
- Harmonization Code 8501.40.3040
- Manufacturer Upc Number 786382001971
- UPC_NO 786382001971
- Manufacturer Product Page Contact Global Electronic Services
- Model K055JWR9666022B
- Motor Category Yoke Pedestal Fan Motor
- Max Allowable Current 4.2 A
- Product Types AC Motors
- Torque 15.32 ft-lbs
- Opposite Drive End Bearing Ball
- Product Type General Purpose Motors
