US Motors (Nidec) Electric Motors Model 1875 Service, Sales, Replacement Parts
US Motors (Nidec) 1875 US Motors (Nidec) Electric Motors Model 1875 Service, Sales, Replacement Parts
Product information
Key Features
- Motor Phase 1 ph
- Motor Horsepower 1/3 hp / 1/5 hp
- Synchronous Rpm 900 rpm
- Country of Origin MEX
- Motor Supply Voltage 208-230 V
- Frame Size 48Y
- Enclosure Type TEAO (Totally Enclosed Air Over)
- Frequency Rating 60 Hz
- Base RPM 825 rpm
- Duty Condition Type Continuous Duty
US Motors (Nidec)
- Model #:
- 1875
- Part #:
- 1875
- New/Surplus $ 209
- Refurb. Price $146 Save up to $ 63
- Repair Price $105 Save up to $ 104
1875 US Motors (Nidec) | BUY OR REPAIR
Overview
Condenser Fan Motor (Multi Speed) – 1/3 hp / 1/5 hp, 900 rpm, 1 ph, 208-230 V, 48Y Frame, TEAO (Totally Enclosed Air Over) Enclosure, 60 Hz, 825 rpm Base, Stud Mount, Continuous Duty
Features
- Motor Phase 1 ph
- Motor Horsepower 1/3 hp / 1/5 hp
- Synchronous Rpm 900 rpm
- Country of Origin MEX
- Motor Supply Voltage 208-230 V
- Frame Size 48Y
- Enclosure Type TEAO (Totally Enclosed Air Over)
- Frequency Rating 60 Hz
- Base RPM 825 rpm
- Duty Condition Type Continuous Duty
- Mounting Type Stud
- Thermal Protection Automatic Reset
- Motor Poles 8
- Description US Motors (Nidec) Electric Motors 1875
- Description Keyword 1/3 hp / 1/5 hp
- Service Factor 1.00
- Frame Material Steel
- Insulation Class B
- Weight 14.54 lbs
- Harmonization Code 8501.40.3040
- Manufacturer Upc Number 786382001803
- UPC_NO 786382001803
- Manufacturer Product Page Contact Global Electronic Services
- Model K055CLL1467012B
- Motor Category Condenser Fan Motor (Multi-Speed)
- Max Allowable Current 1.4 to 2.4 A
- Product Types AC Motors
- Torque 33.02 ft-lbs
- Opposite Drive End Bearing Self-Aligning Bearing (SAB)
- Product Type General Purpose Motors
