Product information
Key Features
- Motor Phase 1 ph
- Motor Horsepower 1/2 hp
- Synchronous Rpm 1200 rpm
- Country of Origin MEX
- Motor Supply Voltage 115 V
- Frame Size 56
- Enclosure Type OAO (Open Air-Over)
- Frequency Rating 60 Hz
- Base RPM 1075 rpm
- Duty Condition Type Continuous Duty
US Motors (Nidec)
- Model #:
- 1865
- Part #:
- 1865
- New/Surplus $ 212
- Refurb. Price $148 Save up to $ 64
- Repair Price $106 Save up to $ 106
1865 US Motors (Nidec) | BUY OR REPAIR
Overview
Blower/Fan Motor – 1/2 hp, 1200 rpm, 1 ph, 115 V, 56 Frame, OAO (Open Air-Over) Enclosure, 60 Hz, 1075 rpm Base, Band / Hub / Stud Mount, Continuous Duty
Features
- Motor Phase 1 ph
- Motor Horsepower 1/2 hp
- Synchronous Rpm 1200 rpm
- Country of Origin MEX
- Motor Supply Voltage 115 V
- Frame Size 56
- Enclosure Type OAO (Open Air-Over)
- Frequency Rating 60 Hz
- Base RPM 1075 rpm
- Duty Condition Type Continuous Duty
- Mounting Type Band / Hub / Stud
- Thermal Protection Automatic Reset
- Full Load Current 6.50 A
- Motor Poles 6
- Number Of Speeds 3
- Description US Motors (Nidec) Electric Motors 1865
- Description Keyword 1/2 hp
- Overall Length C Dimension 10.4 in
- Service Factor 1.00
- Frame Material Steel
- Insulation Class B
- Weight 15.84 lbs
- Applications Commercial Residential
- Harmonization Code 8501.40.3040
- Manufacturer Upc Number 786382001742
- UPC_NO 786382001742
- Manufacturer Catalog Contact Global Electronic Services
- Model K055WRB1435012B
- Motor Category Blower/Fan Motor
- Max Allowable Current 6.5 A
- Product Types AC Motors
- Torque 38.99 ft-lbs
- Opposite Drive End Bearing Self-Aligning Bearing (SAB)
- Product Type General Purpose Motors
