US Motors (Nidec) Electric Motors Model 1837 Service, Sales, Replacement Parts
US Motors (Nidec) 1837 US Motors (Nidec) Electric Motors Model 1837 Service, Sales, Replacement Parts
Product information
Key Features
- Motor Phase 1 ph
- Motor Horsepower 1 hp
- Synchronous Rpm 900 rpm
- Country of Origin MEX
- Motor Supply Voltage 230 V
- Frame Size 56YZ
- Enclosure Type TEAO (Totally Enclosed Air Over)
- Frequency Rating 60 Hz
- Base RPM 850 rpm
- Duty Condition Type Continuous Duty
US Motors (Nidec)
- Model #:
- 1837
- Part #:
- 1837
- New/Surplus $ 1267
- Refurb. Price $887 Save up to $ 380
- Repair Price $634 Save up to $ 633
1837 US Motors (Nidec) | BUY OR REPAIR
Overview
Farm Duty – Incubator Hatchery Motor – 1 hp, 900 rpm, 1 ph, 230 V, 56YZ Frame, TEAO (Totally Enclosed Air Over) Enclosure, 60 Hz, 850 rpm Base, C-Face Flange Mount, Continuous Duty
Features
- Motor Phase 1 ph
- Motor Horsepower 1 hp
- Synchronous Rpm 900 rpm
- Country of Origin MEX
- Motor Supply Voltage 230 V
- Frame Size 56YZ
- Enclosure Type TEAO (Totally Enclosed Air Over)
- Frequency Rating 60 Hz
- Base RPM 850 rpm
- Duty Condition Type Continuous Duty
- Mounting Type C-Face Flange
- Thermal Protection Automatic Reset
- Full Load Current 5.20 A
- Full Load Efficiency 66.0 %
- Motor Poles 8
- Description US Motors (Nidec) Electric Motors 1837
- Description Keyword 1 hp
- Shaft Diameter 0.6250 in
- Overall Length C Dimension 13.2 in
- Service Factor 1.00
- Frame Material Steel
- Insulation Class F
- Standards Met NEMA
- Weight 32 lbs
- Applications Direct Drive Exhaust Livestock Houses Vent Fans In Poultry
- Harmonization Code 8501.40.6040
- Manufacturer Upc Number 786382001537
- UPC_NO 786382001537
- Manufacturer Catalog Contact Global Electronic Services
- Model K063DYJ4422021B
- Motor Category Incubator Hatchery Motor
- Max Allowable Current 5.2 A
- Product Types AC Motors
- Torque 98.83 ft-lbs
- Opposite Drive End Bearing Ball
- Product Type General Purpose Motors
