Product information
Key Features
- Frame Size 80
- Enclosure Type TEFC (Totally Enclosed Fan Cooled)
- Frequency Rating 60
- Assembly Box Mounting F3
- Mounting Type B3 Flange
- Electrical Type Capacitor Start Capacitor Run
- KVA Code G
- Motor Orientation Horizontal
- Number Of Speeds 1
- Starting Method Across The Line
LEESON (RRX)
- Model #:
- 192259.00
- Part #:
- 192259.00
- New/Surplus $ 1713
- Refurb. Price $1199 Save up to $ 514
- Repair Price $857 Save up to $ 856
192259.00 LEESON (RRX) | BUY OR REPAIR
Overview
1 HP General Purpose, 1 phase, 1800 RPM, 115/230 V, 80 Frame, TEFC
Features
- Frame Size 80
- Enclosure Type TEFC (Totally Enclosed Fan Cooled)
- Frequency Rating 60
- Assembly Box Mounting F3
- Mounting Type B3 Flange
- Electrical Type Capacitor Start Capacitor Run
- KVA Code G
- Motor Orientation Horizontal
- Number Of Speeds 1
- Starting Method Across The Line
- Shaft Diameter 0.7500 in
- Shaft Type IEC
- Opposite Drive End Bearing Type Ball
- NEMA Design Class N
- Service Factor 1.15
- Frame Material Aluminum
- Insulation Class F
- IP Rating 55
- Drive End Bearing Size 6204
- Opposite Drive End Bearing Size 6203
- Overload Protector Manual
- Weight 38.00 lbs
- UPC_NO 691720108550
- Voltage 115/230 V
- Product Type General Purpose Motors
